Features
SENSI-TEMP TECHNOLOGY
Enjoy the same cooking power as a traditional coil.
STANDARD CLEAN OVEN
Standard clean oven smooth surface and rounded corners make clean-up quick and easy.
DUAL-ELEMENT BAKE
Upper and lower elements produce even heat and great results.
Additional Features
REMOVABLE FULL-WIDTH STORAGE DRAWER
Store cookware or kitchen accessories
ELECTRONIC CLOCK AND TIMER
Features a convenient digital clock and easy-to-use time with an audible signal to help coordinate cooking times in the kitchen.
Specifications
General
Fuel Type
Electric
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Appliance Care
Standard Care
Cooktop
Burners/Elements
4
Burners/Elements Output
• Element - Left Front: 1250W Temp Limiting Coil
• Element - Left Rear: 2400W Temp Limiting Coil
• Element - Right Front: 2400W Temp Limiting Coil
• Element - Right Rear: 1250W Temp Limiting Coil
• Element - Left Rear: 2400W Temp Limiting Coil
• Element - Right Front: 2400W Temp Limiting Coil
• Element - Right Rear: 1250W Temp Limiting Coil
Burner/Element Size
• Element - Left Front: 6"
• Element - Left Rear: 8"
• Element - Right Front: 8"
• Element - Right Rear: 6"
• Element - Left Rear: 8"
• Element - Right Front: 8"
• Element - Right Rear: 6"
Elements
Coil
Oven
Capacity (cu. ft.)
5.0 cu. ft.
Number of Ovens
Single
Programs
• Audible Preheat Signal
• Auto Oven Shut-Off with Override
• Electronic Clock & Kitchen Timer
• Hi / Low Broil
• Oven "ON" Light
• Auto Oven Shut-Off with Override
• Electronic Clock & Kitchen Timer
• Hi / Low Broil
• Oven "ON" Light
Features
Technologies
Sensi-temp technology
Control Lock
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• Removable full-width storage drawer
• Electronic clock and timer
• Dual-element Bake
• Control Knobs: Gloss Black
• Handle: Designer Style, Stainless Steel
• Oven Door Features: Big View Oven Window, Glass Door
• Textured Steel Side Panels
• Cooktop Surface: One-Piece Upswept Porcelain-Enamel
• Backsplash control
• Control Type: Digital Temperature Display, Electronic, Touchpads
• Removable One-Piece Drip Bowls: Black Porcelain Enameled
• Heating Element "ON" Indicator Light
• Lift-Up Cooktop With Support Rods
• Oven Features: 4-Pass Bake Element, 4-Pass Broil Element
• Oven Rack Features: 2 Oven Racks, 6 Rack Positions
• 1 Incandescent Light
• Electronic clock and timer
• Dual-element Bake
• Control Knobs: Gloss Black
• Handle: Designer Style, Stainless Steel
• Oven Door Features: Big View Oven Window, Glass Door
• Textured Steel Side Panels
• Cooktop Surface: One-Piece Upswept Porcelain-Enamel
• Backsplash control
• Control Type: Digital Temperature Display, Electronic, Touchpads
• Removable One-Piece Drip Bowls: Black Porcelain Enameled
• Heating Element "ON" Indicator Light
• Lift-Up Cooktop With Support Rods
• Oven Features: 4-Pass Bake Element, 4-Pass Broil Element
• Oven Rack Features: 2 Oven Racks, 6 Rack Positions
• 1 Incandescent Light
Electrical Information
Information
• Amp Rating at 208V: 40
• Amp Rating at 240V: 40
• Bake Wattage: 2585W
• Broiler Wattage: 3410W
• KW Rating at 208V: 7.6
• KW Rating at 240V: 10.2
• Amp Rating at 240V: 40
• Bake Wattage: 2585W
• Broiler Wattage: 3410W
• KW Rating at 208V: 7.6
• KW Rating at 240V: 10.2
Certifications and Approvals
Sabbath/Star-K
Yes
Dimensions
Class Width
30"
Width
30 inch(es) / 76.20 cm
Height
47 inch(es) / 119.38 cm
Depth (Without Handles)
26.25 inch(es) / 66.68 cm
Depth (Including Handles)
28.75 inch(es) / 73.02 cm
Weight
142 lb(s) / 64.41 kg
Additional Dimensions
• Cabinet Width: 30.0 in
• Oven Interior Dimensions (W x H x D) (in.): 23-3/4 x 19 x 18-1/2
• Depth with Door Open: 46.25 in
• Height to Cooking Surface (in.): 36 - 36 1/2
• Oven Interior Dimensions (W x H x D) (in.): 23-3/4 x 19 x 18-1/2
• Depth with Door Open: 46.25 in
• Height to Cooking Surface (in.): 36 - 36 1/2
Shipping Dimensions
Width
32.5 inch(es) / 82.55 cm
Height
49.9 inch(es) / 126.75 cm
Depth
31.1 inch(es) / 78.99 cm
Weight
162 lb(s) / 73.48 kg
Warranty
Warranty
• Parts Warranty: Limited 1-year entire appliance
• Labor Warranty: Limited 1-year entire appliance
• Labor Warranty: Limited 1-year entire appliance
UPC
UPC#
084691906698
