Features
WIFI CONNECT
Control your oven with your smart device or simply your voice using WiFi Connect.
EDGE-TO-EDGE GLASS COOKTOP
A sleek look is yours with an edge-to-edge glass cooktop that provides a seamless, easy-to-clean surface with more usable cooking space for five course meals.
12"/9"/6" 3,600-WATT POWER BOIL
Tailor your burner size to your cookware with a 12"/9"/6" element with Power Boil.
Specifications
General
Fuel Type
Electric
Installation Type
Slide-in
Color
Black
Manufacturer Color
Matte Black
Appliance Care
• Self-Clean
• Steam Clean
• Steam Clean
Cooktop
Burners/Elements
5
Burners/Elements Output
• Left Front: 1,900 W
• Left Rear: 2,000 W
• Right Front: 3,600 W Power Boil
• Right Rear: 1,200 W
• Center: 80 W Warming Zone
• Left Rear: 2,000 W
• Right Front: 3,600 W Power Boil
• Right Rear: 1,200 W
• Center: 80 W Warming Zone
Burner/Element Size
• Left Front: 8"/5"
• Left Rear: 8"
• Right Front: 12"/9"/6"
• Right Rear: 6"
• Center: 6"
• Left Rear: 8"
• Right Front: 12"/9"/6"
• Right Rear: 6"
• Center: 6"
Elements
Smoothtop
Oven
Capacity (cu. ft.)
5.7 cu.ft.
Number of Ovens
Single
Programs
• Convection Bake
• Convection Roast
• Convection Roast
Features
Technologies
• Chef Connect
• True European Convection with Precise Air
• Amazon Alexa
• DiGiorno
• Drop
• IFTTT
• Innit
• Nest
• The Google Assistant
• True European Convection with Precise Air
• Amazon Alexa
• DiGiorno
• Drop
• IFTTT
• Innit
• Nest
• The Google Assistant
Control Lock
Yes
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Wi-Fi
Yes
Additional Information
• Audible Preheat Signal
• Auto Oven Shut-Off with Override
• Auto Recipe Conversion
• Auto Self Clean
• C° or F° Programmable
• Delay Bake Option (Time Bake)
• Delay Clean Option
• Electronic Clock & Kitchen Timer
• Fast Preheat
• Hi / Low Broil
• Oven "ON" Light
• Self-Clean Cool Down Time Display
• Temperature Probe
• Warm Mode
• Bake Wattage: 2850W
• Broiler Wattage: 4000W
• Convection Wattage: 2500W
• Big View Oven Window
• Auto Oven Shut-Off with Override
• Auto Recipe Conversion
• Auto Self Clean
• C° or F° Programmable
• Delay Bake Option (Time Bake)
• Delay Clean Option
• Electronic Clock & Kitchen Timer
• Fast Preheat
• Hi / Low Broil
• Oven "ON" Light
• Self-Clean Cool Down Time Display
• Temperature Probe
• Warm Mode
• Bake Wattage: 2850W
• Broiler Wattage: 4000W
• Convection Wattage: 2500W
• Big View Oven Window
Drawer Features
Warming
Yes
Electrical Information
Information
• 208 V / 240 V
• 40 A
• 40 A
Certifications and Approvals
Sabbath/Star-K
Yes
Accessories
Optional
• CXFCEHKPMBT
• CXFCEHKPMBZ
• CXFCEHKPMCU
• Trim Kit: JXFILLR1BB
• CXFCEHKPMBZ
• CXFCEHKPMCU
• Trim Kit: JXFILLR1BB
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
37.37 inch(es) / 94.93 cm
Depth (Without Handles)
26.87 inch(es) / 68.26 cm
Depth (Including Handles)
29.5 inch(es) / 74.93 cm
Weight
206 lb(s) / 93.44 kg
Additional Dimensions
Oven Interior Dimensions (W x H x D): 24" x 19-7/8" x 20-5/8"
Shipping Dimensions
Width
32.7 inch(es) / 83.06 cm
Height
44.5 inch(es) / 113.03 cm
Depth
31.5 inch(es) / 80.01 cm
Weight
291.01 lb(s) / 132.00 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
084691832324
